1t - 20t Digital Hanging Crane Hook , OCS Electronic Crane Scale

Name: 1t 20t Digital Hanging Crane Hook OCS Electronic Crane Scale
Brand: Nante
Price: 1 USD

Place of Origin : Zhejiang, China

Brand Name : Nante

Certification : ISO9001, CE

Model Number : HD

MOQ : 1pc

Price : N/A

Packaging Details : Seaworthy packing

Delivery Time : Within 14 days

Payment Terms : T/T, L/C

Supply Ability : 10000pcs per year

Contact Now

1t - 20t Digital Hanging Crane Hook , OCS Electronic Crane Scale

Quick Details

Place of Origin: Zhejiang, China (Mainland)
Model Number: OCS-A4
Power Supply: Battery
Display Type: LED display
Rated Load: 1t~20t
Accuracy: Digital Calibration
Capacity: 1t~20t

Introduction

Crane scales are used to measure the weight of a load as it is lifted, typically by a crane, hoist or winch.

From material handling, to proof testing and controlled tensioning, we offer a wide selection of crane scales for sale with features and capacities to meet a large variety of your weighing needs like peak hold and battery power.

Our crane scale weighs up to 1000 pounds in 0.5 pound intervals. A higher capacity is also available.

Specifications

High capacity rechargeable battery
American standard bow shackle
American standard eye hook

Parameters

Size and weight
Max.Cap	A	B	C	L	N.W
(t)	mm	mm	mm	mm	(kg)
1t	58	83	30	420	12kg
2t	58	83	30	420	13kg
3t	73	107	33	480	15kg
5t	92	135	45	585	24kg
10t	94	147	60	770	43kg
15t	128	178	75	860	61kg
20t	135	250	75	950	64kg

Functions
Zero	Overload Alarm/ Record
Tare In/ Tare Out	Digital Calibration
Hold	3-point Linearity Correction
Low Voltage Alarm	lb/kg Switch
Battery Supervision	Gravity Acceleration Set

Specification
Accuracy class	OIML III
Tare range	100%F.S.
Zero range	4%F.S.
Safe overload	120%F.S.
Ultimate overload	400%F.S.
Overload alarm	100%F.S.+9e
Battery	6V/10Ah
Adaptor	DC9V
Battery life	>100h
Temperature range	-10°C~40°C

Features

High-strength load receptor

Aluminum die-casting case

LED display

American standard bow shackle

American standard eye hook

High capacity rechargeable battery

Infrared remote control

Capacity:1t~20t

Diagram
